PRODUCT NAME
Connector of Galvanized Pipe and Corrugated Pipe
Materials: UL approved Nylon PA66PA 66(Flammability UL 94V-2)for A. C. F parts, Weather-resistant EPDM rubber for B. D parts. (Accept to make super rubber: resist high temperature rubber, resist strong acid/alkali,etc).
Working temperature: -40℃ to 100℃
Features: The Powerful Galvanized Pipe Fittings build the best tightening power by a very high and active compression force，waterproof IP68 design, perfect connecting of galvanized pipe and corrugated pipe.The product can widely applied to resist water as a tough cable protection system for any machines, electric power equipment, engineering installation with the very specific demands.
| Item.No. | Adapt to galvanized pipe(mm) | Adapt to galvanized pipe(Inch) | Adapt to Corrugated pipe |
|---|---|---|---|
| DN15/AD21.2-AD15.8 | 21.3mm | 1/2 | AD15.8 |
| DN15/AD21.2-AD18.5 | 21.3mm | 1/2 | AD18.5 |
| DN20/AD28.5-AD21.2 | 26.8mm（26.9mm） | 3/4 | AD21.2 |
| DN25/AD34.5-AD25.0 | 33.5mm（33.7mm） | 1 | AD25.0 |
| DN25/AD34.5-AD28.5 | 33.5mm（33.7mm） | 1 | AD28.5 |
| DN32/AD42.5-AD34.5 | 42.25mm（42.4mm） | 1-1/4 | AD34.5 |
| DN40/AD48.0-AD42.5 | 48mm | 1-1/2 | AD42.5 |
| DN50/AD54.5-AD54.5 | 60mm | 2 | AD54.5 |
