PRODUCT NAME
Double fixed for cables and flexible pipes
Thread: Metric, PG, G (PF/BSP/PS), and NPT thread
Materials: UL approved Nylon PA66 (Flammability UL 94V-2)；（Accept to make flammability UL 94V-0 ）
Working temperature: -40℃ to 100℃
Features: The claws of excellent design, to provide a fast & safe
connection with the tubing and to get an excellent result of the pullout
strength to be the best balanced performers for cable protection
system.
Color: Black(RAL9005), other colors are available upon request.
| Item. No. (Inner thread quick connector fit cable glands) |
Accommodated Pipes |
Accommodated QNE cable glands |
|---|---|---|
| ITF-AD10+NCG-M12S-5.5 | AD10 | NCG-M12S -5.5 |
| ITF-AD10+NCG-M12S-6.5 | AD10 | NCG-M12S -6.5 |
| ITF-AD10+NCG-M12SL-5.5 | AD10 | NCG-M12SL-5.5 |
| ITF-AD10+NCG-M12SL-6.5 | AD10 | NCG-M12SL-6.5 |
| ITF-AD10+NCG-PG7S-5.5 | AD10 | NCG-PG7S -5.5 |
| ITF-AD10+NCG-PG7S-6.5 | AD10 | NCG-PG7S -6.5 |
| ITF-AD10+NCG-PG7SL-5.5 | AD10 | NCG-PG7SL-5.5 |
| ITF-AD10+NCG-PG7SL-6.5 | AD10 | NCG-PG7SL-6.5 |
| ITF-AD13+NCG-M12-5 | AD13 | NCG-M12 -5 |
| ITF-AD13+NCG-M12 -7 | AD13 | NCG-M12 -7 |
| ITF-AD13+NCG-M12L -5 | AD13 | NCG-M12L -5 |
| ITF-AD13+NCG-M12L -7 | AD13 | NCG-M12L -7 |
| ITF-AD13+NCG-M16S -5 | AD13 | NCG-M16S -5 |
| ITF-AD13+NCG-M16S -8 | AD13 | NCG-M16S -8 |
| ITF-AD13+NCG-M16SL-5 | AD13 | NCG-M16SL-5 |
| ITF-AD13+NCG-M16SL-8 | AD13 | NCG-M16SL-8 |
| ITF-AD13+NCG-PG7 -5 | AD13 | NCG-PG7 -5 |
| ITF-AD13+NCG-PG7 -7 | AD13 | NCG-PG7 -7 |
| ITF-AD13+NCG-PG9 -5.5 | AD13 | NCG-PG9 -5.5 |
| ITF-AD13+NCG-PG9 -7.5 | AD13 | NCG-PG9 -7.5 |
| ITF-AD13+NCG-PG9L -5.5 | AD13 | NCG-PG9L -5.5 |
| ITF-AD13+NCG-PG9L -7.5 | AD13 | NCG-PG9L -7.5 |
| ITF-AD13+NCG-G1/4 -5 | AD13 | NCG-G1/4 -5 |
| ITF-AD13+NCG-G1/4 -8 | AD13 | NCG-G1/4 -8 |
| ITF-AD13+NCG-NPT1/4 -5.5 | AD13 | NCG-NPT1/4 -5.5 |
| ITF-AD13+NCG-NPT1/4 -6.8 | AD13 | NCG-NPT1/4 -6.8 |
| ITF-AD13+NCG-M12A -5.5 | AD13 | NCG-M12A -5.5 |
| ITF-AD13+NCG-M12A -8 | AD13 | NCG-M12A -8 |
| ITF-AD13+NCG-M16AS -5.5-ST | AD13 | NCG-M16AS -5.5-ST |
| ITF-AD13+NCG-M16AS -8-ST | AD13 | NCG-M16AS -8-ST |
| ITF-AD13+NCG-PG7A -5.5 | AD13 | NCG-PG7A -5.5 |
| ITF-AD13+NCG-PG7A -8 | AD13 | NCG-PG7A -8 |
| ITF-AD13+NCG-PG9A -5.5 | AD13 | NCG-PG9A -5.5 |
| ITF-AD13+NCG-PG9A -8 | AD13 | NCG-PG9A -8 |
| ITF-AD13+NCG-G 1/4A -5.5 | AD13 | NCG-G 1/4A -5.5 |
| ITF-AD13+NCG-G 1/4A -8 | AD13 | NCG-G 1/4A -8 |
| ITF-AD15.8+NCG-M16 -7 | AD15.8 | NCG-M16 -7 |
| ITF-AD15.8+NCG-M16 -10 | AD15.8 | NCG-M16 -10 |
| ITF-AD15.8+NCG-M16L -7 | AD15.8 | NCG-M16L -7 |
| ITF-AD15.8+NCG-M16L -10 | AD15.8 | NCG-M16L -10 |
| ITF-AD15.8+NCG-M18 -7 | AD15.8 | NCG-M18 -7 |
| ITF-AD15.8+NCG-M18 -10 | AD15.8 | NCG-M18 -10 |
| ITF-AD15.8+NCG-M18L -7 | AD15.8 | NCG-M18L -7 |
| ITF-AD15.8+NCG-M18L -10 | AD15.8 | NCG-M18L -10 |
| ITF-AD15.8+NCG-M20M -7 | AD15.8 | NCG-M20M -7 |
| ITF-AD15.8+NCG-M20M -10 | AD15.8 | NCG-M20M -10 |
| ITF-AD15.8+NCG-PG11 -7 | AD15.8 | NCG-PG11 -7 |
| ITF-AD15.8+NCG-PG11 -10 | AD15.8 | NCG-PG11 -10 |
| ITF-AD15.8+NCG-PG11L -7 | AD15.8 | NCG-PG11L -7 |
| ITF-AD15.8+NCG-PG11L -10 | AD15.8 | NCG-PG11L -10 |
| ITF-AD15.8+NCG-G3/8 -7 | AD15.8 | NCG-G3/8 -7 |
| ITF-AD15.8+NCG-G3/8 -10 | AD15.8 | NCG-G3/8 -10 |
| ITF-AD15.8+NCG-NPT3/8 -7 | AD15.8 | NCG-NPT3/8 -7 |
| ITF-AD15.8+NCG-NPT3/8 -10 | AD15.8 | NCG-NPT3/8 -10 |
| ITF-AD15.8+NCG-M16A -7-ST | AD15.8 | NCG-M16A -7-ST |
| ITF-AD15.8+NCG-M16A -10-ST | AD15.8 | NCG-M16A -10-ST |
| ITF-AD15.8+NCG-M16AL -7 | AD15.8 | NCG-M16AL -7 |
| ITF-AD15.8+NCG-M16AL -10 | AD15.8 | NCG-M16AL -10 |
| ITF-AD15.8+NCG-PG11A -7 | AD15.8 | NCG-PG11A -7 |
| ITF-AD15.8+NCG-PG11A -10 | AD15.8 | NCG-PG11A -10 |
| ITF-AD15.8+NCG-G 3/8AL -7 | AD15.8 | NCG-G 3/8AL -7 |
| ITF-AD15.8+NCG-G 3/8AL -10 | AD15.8 | NCG-G 3/8AL -10 |
| ITF-AD18.5+NCG-M20S -9 | AD18.5 | NCG-M20S -9 |
| ITF-AD18.5+NCG-M20S -12.5 | AD18.5 | NCG-M20S -12.5 |
| ITF-AD18.5+NCG-M20SL -9 | AD18.5 | NCG-M20SL -9 |
| ITF-AD18.5+NCG-M20SL-12.5 | AD18.5 | NCG-M20SL-12.5 |
| ITF-AD18.5+NCG-PG13.5-9 | AD18.5 | NCG-PG13.5-9 |
| ITF-AD18.5+NCG-PG13.5-12.5 | AD18.5 | NCG-PG13.5-12.5 |
| ITF-AD18.5+NCG-PG13.5L-9 | AD18.5 | NCG-PG13.5L-9 |
| ITF-AD18.5+NCG-PG13.5L-12.5 | AD18.5 | NCG-PG13.5L-12.5 |
| ITF-AD18.5+NCG-G1/2 -9 | AD18.5 | NCG-G1/2 -9 |
| ITF-AD18.5+NCG-G1/2 -12.5 | AD18.5 | NCG-G1/2 -12.5 |
| ITF-AD18.5+NCG-NPT1/2 -9 | AD18.5 | NCG-NPT1/2 -9 |
| ITF-AD18.5+NCG-NPT1/2 -13 | AD18.5 | NCG-NPT1/2 -13 |
| ITF-AD18.5+NCG-M20AS -9-ST | AD18.5 | NCG-M20AS -9-ST |
| ITF-AD18.5+NCG-M20AS -12.5-ST | AD18.5 | NCG-M20AS -12.5-ST |
| ITF-AD18.5+NCG-PG13.5A-8.8 | AD18.5 | NCG-PG13.5A-8.8 |
| ITF-AD18.5+NCG-PG13.5A-12.5 | AD18.5 | NCG-PG13.5A-12.5 |
| ITF-AD18.5+NCG-PG13.5AL-8.8 | AD18.5 | NCG-PG13.5AL-8.8 |
| ITF-AD18.5+NCG-PG13.5AL-12.5 | AD18.5 | NCG-PG13.5AL-12.5 |
| ITF-AD18.5+NCG-G 1/2AL -11 | AD18.5 | NCG-G 1/2AL -11 |
| ITF-AD18.5+NCG-G 1/2AL -14 | AD18.5 | NCG-G 1/2AL -14 |
| ITF-AD21.2+NCG-M20 -11 | AD21.2 | NCG-M20 -11 |
| ITF-AD21.2+NCG-M20 -13.5 | AD21.2 | NCG-M20 -13.5 |
| ITF-AD21.2+NCG-M20L -11 | AD21.2 | NCG-M20L -11 |
| ITF-AD21.2+NCG-M20L -13.5 | AD21.2 | NCG-M20L -13.5 |
| ITF-AD21.2+NCG-M22 -11 | AD21.2 | NCG-M22 -11 |
| ITF-AD21.2+NCG-M22 -13.5 | AD21.2 | NCG-M22 -13.5 |
| ITF-AD21.2+NCG-PG16 -11 | AD21.2 | NCG-PG16 -11 |
| ITF-AD21.2+NCG-PG16 -14 | AD21.2 | NCG-PG16 -14 |
| ITF-AD21.2+NCG-PG16L -11 | AD21.2 | NCG-PG16L -11 |
| ITF-AD21.2+NCG-PG16L -14 | AD21.2 | NCG-PG16L -14 |
| ITF-AD21.2+NCG-PG19 -11 | AD21.2 | NCG-PG19 -11 |
| ITF-AD21.2+NCG-PG19 -14 | AD21.2 | NCG-PG19 -14 |
| ITF-AD21.2+NCG-M25S -11 | AD21.2 | NCG-M25S -11 |
| ITF-AD21.2+NCG-M25S -14 | AD21.2 | NCG-M25S -14 |
| ITF-AD21.2+NCG-M20A -11-ST | AD21.2 | NCG-M20A -11-ST |
| ITF-AD21.2+NCG-M20A -14-ST | AD21.2 | NCG-M20A -14-ST |
| ITF-AD21.2+NCG-M20AL -11 | AD21.2 | NCG-M20AL -11 |
| ITF-AD21.2+NCG-M20AL -14 | AD21.2 | NCG-M20AL -14 |
| ITF-AD21.2+NCG-M22A -11-ST | AD21.2 | NCG-M22A -11-ST |
| ITF-AD21.2+NCG-M22A -14-ST | AD21.2 | NCG-M22A -14-ST |
| ITF-AD21.2+NCG-M22AL -11-ST | AD21.2 | NCG-M22AL -11-ST |
| ITF-AD21.2+NCG-M22AL -14-ST | AD21.2 | NCG-M22AL -14-ST |
| ITF-AD21.2+NCG-PG16A -11 | AD21.2 | NCG-PG16A -11 |
| ITF-AD21.2+NCG-PG16A -14 | AD21.2 | NCG-PG16A -14 |
| ITF-AD21.2+NCG-G 1/2AL -11 | AD21.2 | NCG-G 1/2AL -11 |
| ITF-AD21.2+NCG-G 1/2AL -14 | AD21.2 | NCG-G 1/2AL -14 |
| ITF-AD28.5+NCG-M25 -13 | AD28.5 | NCG-M25 -13 |
| ITF-AD28.5+NCG-M25 -18 | AD28.5 | NCG-M25 -18 |
| ITF-AD28.5+NCG-M25L -13 | AD28.5 | NCG-M25L -13 |
| ITF-AD28.5+NCG-M25L -18 | AD28.5 | NCG-M25L -18 |
| ITF-AD28.5+NCG-PG21 -13 | AD28.5 | NCG-PG21 -13 |
| ITF-AD28.5+NCG-PG21 -17.5 | AD28.5 | NCG-PG21 -17.5 |
| ITF-AD28.5+NCG-PG21L -13 | AD28.5 | NCG-PG21L -13 |
| ITF-AD28.5+NCG-PG21L -17.5 | AD28.5 | NCG-PG21L -17.5 |
| ITF-AD28.5+NCG-G3/4 -13 | AD28.5 | NCG-G3/4 -13 |
| ITF-AD28.5+NCG-G3/4 -17.5 | AD28.5 | NCG-G3/4 -17.5 |
| ITF-AD28.5+NCG-NPT3/4 -13 | AD28.5 | NCG-NPT3/4 -13 |
| ITF-AD28.5+NCG-NPT3/4 -18 | AD28.5 | NCG-NPT3/4 -18 |
| ITF-AD28.5+NCG-M25A -16-ST | AD28.5 | NCG-M25A -16-ST |
| ITF-AD28.5+NCG-M25A -18-ST | AD28.5 | NCG-M25A -18-ST |
| ITF-AD28.5+NCG-M25AL -16 | AD28.5 | NCG-M25AL -16 |
| ITF-AD28.5+NCG-M25AL -18 | AD28.5 | NCG-M25AL -18 |
| ITF-AD28.5+NCG-PG21A -16 | AD28.5 | NCG-PG21A -16 |
| ITF-AD28.5+NCG-PG21A -18 | AD28.5 | NCG-PG21A -18 |
| ITF-AD28.5+NCG-G 3/4AL -16 | AD28.5 | NCG-G 3/4AL -16 |
| ITF-AD28.5+NCG-G 3/4AL -18 | AD28.5 | NCG-G 3/4AL -18 |
| ITF-AD34.5+NCG-M32 -17.5 | AD34.5 | NCG-M32 -17.5 |
| ITF-AD34.5+NCG-M32 -25 | AD34.5 | NCG-M32 -25 |
| ITF-AD34.5+NCG-M36 -17.5 | AD34.5 | NCG-M36 -17.5 |
| ITF-AD34.5+NCG-M36 -25 | AD34.5 | NCG-M36 -25 |
| ITF-AD34.5+NCG-PG29 -17.5 | AD34.5 | NCG-PG29 -17.5 |
| ITF-AD34.5+NCG-PG29 -25 | AD34.5 | NCG-PG29 -25 |
| ITF-AD34.5+NCG-G1 -17.5 | AD34.5 | NCG-G1 -17.5 |
| ITF-AD34.5+NCG-G1 -25 | AD34.5 | NCG-G1 -25 |
| ITF-AD34.5+NCG-NPT1 -17.5 | AD34.5 | NCG-NPT1 -17.5 |
| ITF-AD34.5+NCG-NPT1 -25 | AD34.5 | NCG-NPT1 -25 |
| ITF-AD34.5+NCG-M32A -22 | AD34.5 | NCG-M32A -22 |
| ITF-AD34.5+NCG-M32A -25 | AD34.5 | NCG-M32A -25 |
| ITF-AD34.5+NCG-PG29A -22 | AD34.5 | NCG-PG29A -22 |
| ITF-AD34.5+NCG-PG29A -24 | AD34.5 | NCG-PG29A -24 |
| ITF-AD34.5+NCG-G 1AL -22 | AD34.5 | NCG-G 1AL -22 |
| ITF-AD34.5+NCG-G 1AL -24 | AD34.5 | NCG-G 1AL -24 |
| ITF-AD42.5+NCG-M40 -26.5 | AD42.5 | NCG-M40 -26.5 |
| ITF-AD42.5+NCG-M40 -31 | AD42.5 | NCG-M40 -31 |
| ITF-AD42.5+NCG-PG36 -25.5 | AD42.5 | NCG-PG36 -25.5 |
| ITF-AD42.5+NCG-PG36 -31 | AD42.5 | NCG-PG36 -31 |
| ITF-AD42.5+NCG-G11/4-25.5 | AD42.5 | NCG-G11/4-25.5 |
| ITF-AD42.5+NCG-G11/4-31 | AD42.5 | NCG-G11/4-31 |
| ITF-AD42.5+NCG-NPT11/4-25.5 | AD42.5 | NCG-NPT11/4-25.5 |
| ITF-AD42.5+NCG-NPT11/4-31 | AD42.5 | NCG-NPT11/4-31 |
| ITF-AD42.5+NCG-M40A -26 | AD42.5 | NCG-M40A -26 |
| ITF-AD42.5+NCG-M40A -31 | AD42.5 | NCG-M40A -31 |
| ITF-AD42.5+NCG-PG36A -26 | AD42.5 | NCG-PG36A -26 |
| ITF-AD42.5+NCG-PG36A -31 | AD42.5 | NCG-PG36A -31 |
| ITF-AD42.5+NCG-G 1 1/4AL -26 | AD42.5 | NCG-G 1 1/4AL -26 |
| ITF-AD42.5+NCG-G 1 1/4AL -31 | AD42.5 | NCG-G 1 1/4AL -31 |
