PRODUCT NAME
PVC Coated Flexible Conduit(JSH)
Product Specification:
1. Coated JS metal conduit with PVC material.
2.
Good flexibility, twist resistance and good bending performance, able
to bear heavy loads; Acid resistant, lubricant resistant and coolant
resistant; Luster on surface and abrasion resistant.
3. The structure is buckle structure, whick enhances the pull resistance and is not liable to crack or deform.
4. JSH PVC coated flexible conduit can be used for high requirement connection.
| Specification | Inner diameter (mm) |
Outer Diameter (mm) |
Distance (mm) |
Packaging (meter) |
Suitable pipes |
||
|---|---|---|---|---|---|---|---|
| Metric System G |
System | Thin steel |
Thick steel |
||||
| Ф6 | 5.7 | 8.2 | 2.7 | 100 | |||
| Ф8 | 7.4 | 11.8 | 4 | 100 | |||
| Ф10 | 5/16 | 9.4 | 14.5 | 4.7 | 100 | #12 - 1/2 | |
| Ф12 | 1/4 | 11.4 | 16.5 | 4.7 | 100 | #15 - 5/8 | #10 - 3/8 |
| Ф15 | 3/8 | 14.4 | 20.2 | 5.7 | 100 | #20 - 3/4 | #15 - 1/2 |
| Ф20 | 1/2 | 19.3 | 24.5 | 6.4 | 50 | #25 - 1 | #20 - 3/4 |
| Ф25 | 3/4 | 24 | 31.7 | 8.7 | 50 | #32 - 1/1/4 | #25 - 1 |
| Ф32 | 1/1/4 | 31 | 39.6 | 10.5 | 25 | #40 - 1/1/2 | #32 - 1/1/4 |
| Ф38 | 1/1/2 | 37 | 46.6 | 11.4 | 25 | #50 - 2 | #40 - 1/1/2 |
| Ф51 | 2 | 49 | 59.6 | 11.4 | 20 | #70 - 2/1/2 | #50 - 2 |
| Ф64 | 2/1/2 | 62 | 74 | 14.2 | 10 | #70 - 2/1/2 | |
| Ф75 | 3 | 72.5 | 85 | 14.2 | 10 | #80 - 3 | |
| Ф100 | 4 | 96.5 | 109 | 14.2 | 10 | #100 - 4 | |
| Ф125 | 5 | 121.5 | 135.5 | 14.2 | 5 | #125 - 5 | |
| Ф150 | 6 | 145.5 | 161.5 | 14.2 | 5 | #150 - 6 | |
