PRODUCT NAME
Nylon Ferrules For Metal Flexible Conduit
·Material: UL approved Halogen-Free Nylon PA66 flammability UL 94V-2 );
Colours: Black(RAL9005), Gray(RAL7035),other color available upon request. Application: The nylon Ferrules are designed to protect cables from contacting the sharp edged conduit.
| Item. No. | For Conduit Size | A | B1 | B2 | C |
|---|---|---|---|---|---|
| NF5/16 | 5/16＂ | 9.2 | 20 | 20.5 | 20 |
| NF3/8 | 3/8＂ | 10.8 | 20 | 20.5 | 21 |
| NF1/2 | 1/2＂ | 14.2 | 25 | 26 | 24 |
| NF3/4 | 3/4＂ | 18 | 30.5 | 31.5 | 26 |
| NF1 | 1＂ | 23.5 | 36 | 38 | 31 |
| NF1 1/4 | 1 1/4＂ | 32.5 | 45 | 40 | 33 |
| NF1 1/2 | 1 1/2＂ | 37 | 52 | 53 | 36 |
| NF2 | 2＂ | 49 | 64.5 | 65 | 35 |
