PRODUCT NAME
Stuffing Box (TJ )
Materials: Rubber, iron, Galvanized Alloy and thickened zinc or chromium plated.
Features: Galvanized plated, the exterior and the interface are very smooth, coated the outer screw thread with astiseptic oil.
Application: Stuffing Box (TJ ) joint is especially for the use of ship. The joint should be connected tightly
| d | D | d1 | D1 | H | H1 | washer | cable range |
|---|---|---|---|---|---|---|---|
| 8 | M16×1 | M14×1 | 20 | -32 | 10 | 8×14 | 5--7 |
| 13 | M20×1 | M18×1 | 25 | -35 | 11 | 13×18 | 6--12 |
| 16 | M22×1 | M22×1 | 32 | -40 | 11 | 16×24 | 11--15 |
| 19 | M27×1.5 | M27×1.5 | 36 | -42 | 14 | 19×27 | 14--18 |
| 24 | M30×1.5 | M30×1.5 | 42 | -44 | 11 | 24×33 | 17--23 |
| 28 | M36×2 | M36×2 | 48 | -46 | 14 | 28×38 | 22-27 |
| 34 | M42×2 | M42×2 | 54 | -49 | 14 | 34×44 | 26--33 |
| 42 | M52×2 | M52×2 | 62 | -54 | 14 | 42×52 | 32--41 |
| 50 | M58×2 | M58×2 | 70 | -56 | 20 | 50×59 | 40--49 |
| 58 | M68×3 | M68×2 | 78 | -56 | 20 | 58×67 | 48--57 |
