PRODUCT NAME
Nylon venting gland
Thread: Metric thread
Materials: UL approved Nylon PA66 (Flammability UL 94V-2) for A. C. F parts, (Accept to make flammability UL 94V-0 ); EPDM rubber for B. D parts, (Also accept to make super rubber: resist high temperature rubber, resist strong acid/alkali,etc).
Working temperature: -40℃ to 100℃
Features: Cable gland with ventilation function.
| Thread | Item. No. | Cable Range |
Thread O. D. |
Thread Length |
Spanner Size |
Std. Pkg |
|---|---|---|---|---|---|---|
| Ф(mm) | C1(mm) | C2(mm) | A&F(mm) | (pcs) | ||
| M12 x 1.5 | TNCG-M12 -5.5 | 3-5.5 | 12 | 9 | 18/18 | 10 |
| M12 x 1.5 | TNCG-M12 -7.8 | 4.5-8 | 12 | 9 | 18/18 | 10 |
